TRIPLE HANDLE, WATER DISPENSER, COPY MILLING MACHINE WITH REDUCTERS SA510-AL SA510-AL

• The copy milling section door unlocks the espagnolette ducts of the arm nest and the wing profile

• The triple drill section opens the arm holes in the wings.

• The copy milling template is manually controlled with the guidance of the tracking tip.

• Used to open water drainage ducts of PVC profiles.

• The selection of the motor is done by means of buttons.

• Optimal working time avoids time loss

• Pneumatic profile clamping system.

• The profile squeezing process is performed with the hand control valve on the base

• The machine is positioned comfortably with the adjustable feet of the machine

• The milling heads can be freely adjusted to the depth and height.

• Design according to CE norms
